NW Capacity | 8m3 | 12m3 | 16m3 | 25m3 | 34m3 | 40m3 |
---|---|---|---|---|---|---|
Inner size (W*D*H)(cm) | 200*200*200 | 200*300*200 | 220*350*210 | 300*400*210 | 340*480*220 | 400*500*220 |
Outer size (W*D*H)(cm) | 230*360*240 | 230*460*240 | 246*520*250 | 330*560*250 | 370*660*270 | 430*660*270 |
Net weight (kg) | Based on the actual weight | |||||
Exterior material | Standard color steel plate/cold-roll steel sheets with coating/laminating metal sheet | |||||
Interior material | Stainless steel plate SUS#304 | |||||
Temp Range | RT to 80℃/100℃/120℃/150℃/180℃ | |||||
Temp Fluctuation | ±0.5℃ | |||||
Temp Variation in Space | ±2℃ | |||||
Heat Up of Temp | 3℃/min; or customized |
|||||
Floor Load Resistance | Customized | |||||
Door | Single or double door or customized | |||||
Configuration Interface | With USB, WLAN, RS232 port, APP function is optional | |||||
Power supply | AC 380V 50Hz |
