| Capacity | 100L | 150L | 225L | 408L | 800L | 1000L | 1200L | 1500L |
|---|---|---|---|---|---|---|---|---|
| Inner size(W*D*H)(cm) | 50*40*50 | 50*50*60 | 60*50*75 | 80*60*85 | 100*80*100 | 100*100*100 | 120*100*100 | 150*100*100 |
| Outer size(W*D*H)(cm) | 70*100*156 | 70*125*147 | 80*129*168 | 80*140*180 | 120*155*195 | 120*175*195 | 140*175*195 | 170*175*195 |
| Power(KW) | 20 | 25 | 32 | 36 | 40 | 40 | 48 | 52 |
| Exterior Material | Standard 1.5mm electrolytic plate electrostatic spray paint | |||||||
| Interior Material | Stainless steel plate SUS#304 | |||||||
| Insulation | Hard urethane foam | |||||||
| System | Hard urethane foam | |||||||
| Temp Range | Model S:-70℃ to 150℃; Model L:-40℃ to 150℃; or customized | |||||||
| Humid Range | 20%RH to 98%RH(Optional H type only) | |||||||
| Linear Temp Range | -40℃-85℃ | |||||||
| Temp Change Rate | HLinear and average 5℃/min,10℃/min,15℃/min,20℃/min,25℃/min,or customize | |||||||
| T Pull Down Rate | 1℃/min; or customized | |||||||
| Language | Chinese/English/Russian | |||||||
| Configuration Interface | With USB,WLAN,RS232 port,APP function is optional | |||||||
| Power Supply | AC 220 or AC 110V or AC 380V 50Hz | |||||||
